Specification
| Model | Outer diameter (mm) | Color code | Approximate length (mm) | |||||
| C Neck (Φ57mm) | F Neck (Φ73mm) | J Neck (Φ89mm) | Min | Max | C Neck | F Neck | J neck | |
| 14.3mm minimum groove radius | ||||||||
| SDB-57-5460 | SDB-73-5460 | SDB-89-5460 | 4.83 | 5.46 | Blue | 610 | 635 | 660 |
| SDB-57-6200 | SDB-73-6200 | SDB-89-6200 | 5.49 | 6.20 | Brown | 635 | 660 | 685 |
| SDB-57-7040 | SDB-73-7040 | SDB-89-7040 | 6.22 | 7.04 | Orange | 660 | 685 | 710 |
| SDB-57-8000 | SDB-73-8000 | SDB-89-8000 | 7.06 | 8.00 | Purple | 660 | 735 | 760 |
| SDB-57-9070 | SDB-73-9070 | SDB-89-9070 | 8.03 | 9.07 | Red | 710 | 785 | 815 |
| SDB-57-1029 | SDB-73-1029 | SDB-89-1029 | 9.09 | 10.29 | Yellow | 760 | 815 | 840 |
| SDB-57-1166 | SDB-73-1166 | SDB-89-1166 | 10.31 | 11.66 | Blue | 635 | 660 | 685 |
| SDB-57-1321 | SDB-73-1321 | SDB-89-1321 | 11.68 | 13.21 | Orange | 635 | 685 | 710 |
| SDB-57-1494 | SDB-73-1494 | SDB-89-1494 | 13.23 | 14.94 | Red | 710 | 735 | 760 |
| SDB-57-1689 | SDB-73-1689 | SDB-89-1689 | 14.96 | 16.89 | Purple | 760 | 815 | 840 |
| SDB-57-1918 | SDB-73-1918 | SDB-89-1918 | 16.92 | 19.18 | Brown | 785 | 815 | 840 |
| SDB-57-2172 | SDB-73-2172 | SDB-89-2172 | 19.20 | 21.72 | Red | 815 | 840 | 865 |
| 15.9mm minimum groove radius | ||||||||
| SDB-57-2459 | SDB-73-2459 | SDB-89-2459 | 21.74 | 24.59 | Blue | 865 | 890 | 915 |
| 19.1mm minimum groove radius | ||||||||
| SDB-57-2784 | SDB-73-2784 | SDB-89-2784 | 24.61 | 27.84 | Green | 940 | 965 | 990 |
| SDB-57-3150 | SDB-73-3150 | SDB-89-2784 | 27.86 | 31.50 | Yellow | 940 | 1040 | 1065 |
Preformed guy grip production process
Application
We are a manufacturer that integrates research , development and sales of Overhead Transmission Line Hardware, telecom accessories in China. Providing customized services, send us your proposal.
Tags: preformed guy grip , stay rod , cross arm , insulator , cable accessories.hot dip galvanized steel fittings....etc.
